Iridium Oxide Coated Titanium Anode BRIR001

Item Code:BRIR001 Features:Iridium Oxide Coated Titanium Anode
  • Description
  • Base Material: Titanium (Gr1, Gr2, TA1, TA2)
  • Shape: customized
  • Working Current: < 12000 A/㎡
  • Vitriol Content:  <60%
  • Coating Material: IrO+TaO
  • Noble Metal Content: 10--115 g/㎡
  • Content of florin ions: <50 mg/L
  • Temperature:  < 60℃
  • PH Value: 1-12

Properties:  High anti-erosion, High current efficiency, long service life, light, floor can recycled after electrodes lose activity,heavy current density, high productivity,

Application: Foil production, high-speed electroplating, auxiliary anode, cathode protection, organic synthesis, acid water electrolysis,metal surface treament, electrodialysis, electrowinning noble metal and rare metal, horizontal plating, pulse plating.

Other Products

Product Name:
Iridium Oxide Coated Titanium Anode (Tube)
